Globe Valve

Honeywell V5011A1767/U

Globe Valve 2 Way 3" Cast Iron Flange 100Cv

Authorized Distributor

$8,355.27  / ea
Qty
truck image Ships directly to your store or location

FOR PRO PRICE LOGIN OR CREATE AN ACCOUNT

The V5011 Series Single-Seated, Two-Way, Straight-Through Valves provide proportional control of steam and hot or chilled water in HVAC systems requiring tight shutoff.

  • Valves utilize direct mounting valve actuators, Q5020/Q5022 linkages with direct coupled actuators or pneumatic valve actuators to operate the valve
  • Controlled fluid: Chilled or hot water with up to 50% glycol or low pressure steam, not for use with fuels
  • 1-3/8 in bonnet
  • Used with: ML6984/ML7984
  • ML7420/ML7421A/ML7425
  • ML6420,21A,25
  • Q5001/Modutrol IV Motor
  • MP953 actuators
  • Static pressure rating: Meets ANSI 125 standard
  • Stem travel: 3/4 in
  • Capacity: 100 Cv
  • Equal percentage flow characteristic
  • Valve action: Stem down to close
  • For quiet water service 20 psid max differential pressure ratings (close-off)
  • Actuation must be purchased separately

BrandHoneywell
Product Type2-Way
Size3IN
End ConnectionFlange
MaterialCast Iron
Temperature40-250DEG F
ApplicationHeating or Cooling Systems
Shipping Weight58.500 LBS
