Refrigeration Press 3071060000111

3/8" Copper Cap Press

Authorized Distributor

$18.86  / ea
Qty
truck image Ships directly to your store or location

FOR PRO PRICE LOGIN OR CREATE AN ACCOUNT

Secure Caps for Your Pipe Ends.

This 3/8" end cap is made of refrigerant-grade copper (C12200) per ASTM-152. It features a press end connection.

Approved for use with the following refrigerants: R-134A, R-404A, R-407A, R-407C, R-407F, R-407H, R-410A, R-417A, R-421A, R-422B, R-422D, R-424A, R-427A, R-434A, R-437A, R-438A ,R-448A, R-449A,R-450A, R-452A, R-453A, R-456A, R-507A, R-513A, R-513B, R-718, Ethylene Glycol, R-22.
  • Eliminates brazing process using flame-free press tool for safer work environment
  • Fast and reliable connections to save time and money
  • Maximum Rated Pressure (MRP): 700 psi
  • Continuous Operating Temperature: 250 degrees F
  • O-Ring Material: HNBR
  • Made in the USA

BrandRefrigeration Press
Size3/8IN
MaterialCopper
End ConnectionPress
Part Number3071060000111
Pressure700PSI
Temperature250DEG F
ApplicationFlame-Free Refrigerant Fittings
Shipping Weight3.000 LBS
