Damper Actuator

Honeywell M4185B1058/U

Damper Actuator Modutrol IV 2 Position SPST Fast Acting Spring Return Floor 6-7/16 x 5-1/2 x 8-3/4 Inch 24/120/230 Volt 50/60 Hertz

Authorized Distributor

Honeywell
$2,263.10  / ea
Qty
Not available in your location

FOR PRO PRICE LOGIN OR CREATE AN ACCOUNT

Installation Manual
Specification Sheet

  • Wiring box provides NEMA 3 weather protection
  • Integral spring return returns motor to normal position when power is interrupted
  • Spring return motors can operate valve linkages form power end or auxiliary end shafts for normally closed or normally open valve applications
  • All models have dual shafts (slotted and tapped on both ends)
  • All models have auxiliary switch cams
  • Fixed torque throughout the entire voltage range
  • Motor and circuitry operate from 24 VAC models available with factory installed transformer or a field added internal transformer
  • Motors are designed for either normally open or normally closed valves and dampers
  • Normally closed spring return
  • Normally open/normally closed valves and dampers

BrandHoneywell
Product Type2 Position SPST Fast Acting
StyleSpring Return
MountingFloor
Size6-7/16x5-1/2x8-3/4IN
Voltage24/120/230V
Frequency50/60Hz
Torque Rating60LB/IN
Temperature-40 to 150DEG F
Stroke LengthAdjustable 90-160DEG
ApplicationElectric
Length8-3/4IN
Width5-1/2IN
Height6-7/16IN
Shipping Weight10.000 LBS
